2. SPECIFICATIONS
2.1 SPECIFICATIONS
Model
Specifications
H-550A / H-550GA
(mm)
φ550 □550H*600W
(in)
Max
φ21 □21*23
(mm)
φ190 □ 550H * 190W
Cutting Capacity
(in)
Min
φ7.48 □ 21H * 7.48W
Bundle Cutting (mm) 250H*440W
(mm) 41W * 1.30t * 5800L
Blade Size
(in) 1-1/2W * 0.051t * 226L
(m/min ) 25,32,42,55,70,80
Blade Speed
(ft/min) 82,105,138,180,230,260
(kW) Blade 5.6 Hydraulic1.5 Coolant0.1
Motor Output
(HP) Blade 7.5 Hydraulic 2 Coolant 1/8
Hydraulic pressure (bar) 40
(kg) Net / Gross 3800 / 4500
Weight
( lb. ) Net / Gross 8360 / 9900
* Specifications subject to change without notice for improvement and modification.
2.2 STANDARD ACCESSORIES
1. Tools with tool box ..................... 1 set
2. 7 ft.(2M) long roller table ............. 1 set
3. Band-cleaning wire brush ................ 2 pieces
4. Band saw blade .......................... 1 piece
5. Vertical guide rollers .................. 1 set
6. Instruction manual ...................... 1 copy
2-1
