OPERATION
AVTMTTR100-ENG Rev 6 Nov 2015
55
MAIN MENU Screen
After a successful self-test check, the main menu screen (Figure 6-2) appears.
Figure 6-2. Main Menu Screen
1. XFRM. CONFIG.
Allows operator to select single phase, three phase, or T-T
transformer to be tested. The lead connections will be
shown on test setup screen for selected single phase
transformer. For 3 phase and T-T transformers, the lead
connections are shown for each tested phase. Currently
selected transformer configuration is displayed after colon
mark.
2. START QUICK TEST
Allows operator to perform testing with minimal steps and
data entries.
3. START FULL TEST
Allows full testing of transformer. Test report includes
transformer nameplate data, calculated and measured turn
ratio, ratio deviation (%), phase displacement, polarity, IEC
vector group (1PH0 or 1PH6), and winding resistance.
4. CUSTOM CONFIGS.:
Allows complete testing as per START FULL TEST using
up to 100 stored configurations. Custom configurations
are input by operator. The number of stored custom
configurations is displayed after colon mark.
5. SYSTEM SETUP
This menu permits choice of transformer standards, phase
display units, resistance and polarity display, language and
setting of date and time.
6. SAVED READINGS:
Allows viewing, deleting, printing or uploading to PC up to
200 saved test results. The number of saved readings is
displayed after colon mark.
MAIN MENU
1. XFRM. CONFIG.: H-X
2. START QUICK TEST
3. START FULL TEST
4. CUSTOM CONFIG.: 4
5. SYSTEM SETUP
6. SAVED READINGS: 25
SELECT FROM KEYPAD
