OPERATION
AVTMTTR100-ENG Rev 6 Nov 2015
67
System Setup
When selection 4, SYSTEM SETUP, on the MAIN MENU is chosen, the
SYSTEM SETUP MENU screen appears as shown in Figure 6-10.
Figure 6-10. SYSTEM SETUP Screen 1
1. STANDARD: This selection is for entering the desired transformer
standard. Three transformer standards are available to select from: ANSI,
IEC, or AS (Australia Standard). Selecting 1 and using the scroll keys until
the appropriate standard appears on the screen choose the desired
standard by depressing the ENTER key.
2. PHASE: This selection allows a choice of the phase display units:
DEGREES, CENTIRADS or NONE. If DEGREES is selected, any phase
test results below 1 degree will be displayed in minutes. If CENTIRADS is
selected, the phase test results will be displayed in centiradians
(1 centiradian = 0.573 degrees). If NONE is selected, the phase test
results will not be displayed. ). Selecting 2 and using the scroll keys until
the appropriate unit or none appears on the screen choose the entry by
depressing the ENTER key.
3. RESISTANCE TEST: DC winding resistance function can either be active
(YES) or inactive (NO). Selecting 3 and using the scroll keys until the
appropriate functional state is displayed on the screen choose the desired
state by depressing the ENTER key.
4. POLARITY: Polarity test function can either be active (YES) or inactive
(NO). Selecting 4 and using the scroll keys until the appropriate functional
state is displayed on the screen choose the desired state by depressing
the ENTER key.
5. MORE: Selecting 4, an additional SYSTEM SETUP screen is displayed,
Refer to Figure 6-11.
6. MAIN MENU: Selecting 6 or asterisk will return one to the MAIN MENU
screen.
SYSTEM SETUP
1. STANDARD: ANSI
2. PHASE: DEGREES
3. RESISTANCE TEST: YES
4. POLARITY: NO
5. MORE
6. MAIN MENU
SELECT FROM KEYPAD
