15
Delete all data
1. Move the rotary selector switch to the RCL
position. The code rcl is displayed.
2. Press the and keys together. The
code dEL is displayed.
3. Confirm that the data is no longer required by
pressing the key or abort by pressing any
other key. The code
rcl is displayed.
Print Results (see Setup Modes)
1. Connect printer and the instrument with a
serial printer lead.
2. Move the rotary selector switch to the RCL
position. The code rcl is displayed.
3. Commence the printout by pressing the
TEST
button. Abort at any time by pressing and
holding the key. The code rcl is displayed.
Retrieve Stored Results
It is possible to view previously stored test results
by switching the rotary switch to the RCL position.
1. Move the rotary selector switch to the RCL
position. The code rcl is displayed.
2. Select the required distribution board by
pressing the and keys.
The distribution board numbers are shown in
the order that the results were stored. A long
bleep is sounded when the end of the list is
reached.
3. Press the key to list the circuit numbers
used in the currently displayed distribution
board or press the
EXIT button to return to the
RCL display.
4. Select the required circuit number by pressing
the and keys. The circuit numbers
are shown in the order that the results were
stored. A long bleep is sounded when the end
of the list is reached.
5. Press the
EXIT button to return to the
distribution board selection screen, or press
the key to show the stored test codes.
The following codes are used to identify test
results:-
Code Meaning
Con Continuity Test
InS Insulation Test
6. Select the required test by pressing the
and keys. The tests are shown in
∼
∼
∼
∼
