8
MODES OF OPERATION
The DET14C / DET24C can operate in one of three main modes,
selected using the rotary switch:
 OFF – Turn instrument off
 Ω - Resistance measurement
 A - Current measurement
 Fn - Setup and configuration
When in a measurement mode, there are other functions which
are selected using the buttons:
 HOLD – Hold the displayed measurement value.
 – Enable / disable display backlight.
 - Enable / disable buzzer function.
  - Save displayed result to memory.
When in the setup and configuration mode (Fn), some buttons
have different functions:
  - Increment value.
 - Decrement value.
  - Advance to next field.
 OK – Accept value.
Figure 6: Main mode selection using the rotary
switch
Figure 7: Other functions using buttons
