Megger DET5/4D - Chart for Use with Slope Method

Values of P
t / EC
for Values of µ
µ
0123456789
0.40 0.6432 0.6431 0.6429 0.6428 0.6427 0.6425 0.6424 0.6422 0.6421 0.642
0.41 0.6418 0.6417 0.6415 0.6414 0.6412 0.6411 0.641 0.6408 0.6407 0.6405
0.42 0.6404 0.6403 0.6401 0.64 0.6398 0.6397 0.6395 0.6394 0.6393 0.6391
0.43 0.639 0.6388 0.6387 0.6385 0.6384 0.6383 0.6381 0.638 0.6378 0.6377
0.44 0.6375 0.6374 0.6372 0.6371 0.637 0.6368 0.6367 0.6365 0.6364 0.6362
0.45 0.6361 0.6359 0.6358 0.6357 0.6355 0.6354 0.6352 0.6351 0.6349 0.6348
0.46 0.6346 0.6345 0.6344 0.6342 0.6341 0.6339 0.6338 0.6336 0.6335 0.6333
0.47 0.6332 0.633 0.6329 0.6328 0.6326 0.6325 0.6323 0.6322 0.632 0.6319
0.48 0.6317 0.6316 0.6314 0.6313 0.6311 0.631 0.6308 0.6307 0.6306 0.6304
0.49 0.6303 0.6301 0.63 0.6298 0.6297 0.6295 0.6294 0.6292 0.6291 0.6289
0.50 0.6288 0.6286 0.6285 0.6283 0.6282 0.628 0.6279 0.6277 0.6276 0.6274
0.51 0.6273 0.6271 0.627 0.6268 0.6267 0.6266 0.6264 0.6263 0.6261 0.626
0.52 0.6258 0.6257 0.6255 0.6254 0.6252 0.6251 0.6249 0.6248 0.6246 0.6245
0.53 0.6243 0.6242 0.624 0.6239 0.6237 0.6235 0.6234 0.6232 0.6231 0.6229
0.54 0.6228 0.6226 0.6225 0.6223 0.6222 0.622 0.6219 0.6217 0.6216 0.6214
0.55 0.6213 0.6211 0.621 0.6208 0.6207 0.6205 0.6204 0.6202 0.6201 0.6199
0.56 0.6198 0.6196 0.6194 0.6193 0.6191 0.619 0.6188 0.6187 0.6185 0.6184
0.57 0.6182 0.6181 0.6179 0.6178 0.6176 0.6174 0.6173 0.6171 0.617 0.6168
0.58 0.6167 0.6165 0.6164 0.6162 0.6161 0.6159 0.6157 0.6156 0.6154 0.6153
0.59 0.6151 0.615 0.6148 0.6147 0.6145 0.6143 0.6142 0.614 0.6139 0.6137
0.60 0.6136 0.6134 0.6133 0.6131 0.6129 0.6128 0.6126 0.6125 0.6123 0.6122
0.61 0.612 0.6118 0.6117 0.6115 0.6114 0.6112 0.6111 0.6109 0.6107 0.6106
0.62 0.6104 0.6103 0.6101 0.6099 0.6098 0.6096 0.6095 0.6093 0.6092 0.609
0.63 0.6088 0.6087 0.6085 0.6084 0.6082 0.608 0.6079 0.6077 0.6076 0.6074
Chart for use with the Slope Method
