Overview
Range Rotary Switch
The instruments test range of resistance and current is selected with the Range rotary switch.
DLRO10HDX DLRO10HD
2.5
Ω
250
mΩ
µA
100
2.5
kΩ
1mA
10mA
100
mA
1A
1A
10A
10A
250
Ω
25
Ω
2.5
Ω
250
mΩ
25
mΩ
2.5
mΩ
1
5
4
3
2
2
 Green resistance ranges: Low output power (<0.25 W) outputs
 Red resistance ranges: Higher 2.5 W (1 A) and 25 W (10 A) power outputs (
G
shows)
Item Description
1 Date and Time Setup (page 21)
2 Resolution and Accuracy (page 10)
3 Delete Test Result Records (page 24)
4 Download Test Result Records (page 23)
5 Recall Test Result Records (page 22)
