Bridge Balancing
• Select the minimum gain with key F2.
• Set the pointer to the minimum point of the scale with the M
balancing potentiometer. The minimum point may be on the
negative or positive side of the scale
• Press the 0 KORR (F1) key to shift the pointer to the middle of the
scale
• Increase the gain gradually with key F3 and repeat the first three
points until reaching the perfect balance. The balance is perfect
when the gain is 5 and the pointer stands on the minimum
• When the balancing is completed press ENTER to store the result
(ML) and to call the result display.
Displayed Test Results
• ML value
• Lx/L rate
• Unbalance %
To save the test result press the SAVE (F1) key
Notice
The result is calculated out of the measured ML value
