Specifications
7. Specifications
Specification Detail
Transmitter:
Output signal 125 kHz
Voltage Range 12 - 400 V
Frequency Range 0 - 60 Hz
Display LCD display
External Voltage Detection max. 400 V AC/DC
Over Voltage Category CAT Ill 300 V
Pollution Degree 2
Auto Power Off approx.1 hour (after last operation)
Power Supply One 9 V battery, NEDA 1604, IE6F22.Power
Consumption max. 18 mA
Fuse F0.5 A 500 \/, 6.3 x 32 mm
Operating temperature 0 - 40 C, max 80% rel. humidity (not condens.)
Storage temperature -20 - 60 C, max 80% rel. humidity (not condens.)
Altitude up to 2000 m
Dimensions 130 x 69 x 32 mm
Weight approx. 130 g
Receiver:
Tracing depth The tracing depth depends of medium and application
Cable Locator Mode approx. 0 - 2 m (single-pole application)
approx. 0 - 0.5 m (double-pole application)
Voltage detection approx. 0 - 0.4 m
Display LCD with functions- and bar graph
Power Supply One 9 V battery, NEDA 1604, IE6F22.Power
Consumption approx. 23 mA (without backlight or lamp)
approx. 35 mA (with backlight)
max. 40 mA (Backlight and lamp)
Auto Power Off approx. 5 minute (No any Operation )
Operating temperature 0 - 40 C, max 80% rel. humidity (not condens.)
Storage temperature 20 - 60 C, max 80% rel. humidity (not condens.)
Altitude up to 2000 m.
Dimensions 192 x 61 x 37 mm
Weight approx. 180 g
