Circuit Test
Meter reading range: 0 to 9,9 kΩ
Range Resolution Accuracy
0 to 1 kΩ 0,01 kΩ 2,5% of reading ± 0,02 kΩ
1 kΩ to 2 kΩ 0,02 kΩ 2,5% of reading ± 0,02 kΩ
2 kΩ to 5 kΩ 0,05 kΩ 2,5% of reading ± 0,05 kΩ
5 kΩ to 9,9 kΩ 0,1 kΩ 2,5% of reading ± 0,1 kΩ
Open Circuit Voltage: 4,5 V d.c.
Short Circuit Current: 1 mA d.c.
Fuse Check
5 V. d.c. 0,5 mA Typical
Earth Continuity Test
Range Resolution Accuracy
0 to 999 mΩ 1 mΩ 2,5% of reading ±5 mΩ
900 mΩ to1990 mΩ 10 mΩ 2,5% of reading ±10 mΩ
Open Circuit Voltage: Typically 100 mV d.c.
Constant Current: Typically 100 mA into <1Ω
10A Earth Bond Test
Meter reading range: 0 to 1990 mΩ
Range Resolution Accuracy
0 to 600 mΩ 1 mΩ 2,5% of reading ±5 mΩ
600 to 999 mΩ 1 mΩ Current below level for
900-1990 mΩ 10 mΩ satisfactory Bond test.
Transfer to 25A test
Pass Band Limits: 100 and 500 mΩ
Open Circuit Voltage: Typically 3 V rms a.c. 50 Hz
Specification
15
