5 0
T O R K E L 8 2 0 / 8 4 0 / 8 6 0
P r o g r a m m a E l e c t r i c A B
Z P - B S 0 6 E R 1 0 1
18
Specifications
Display range 0.0 – 60 V
Basic inaccuracy ±(0.5% of reading +0.1 V)
Resolution 0.1 V
Display range 0.0 – 500 V
Basic inaccuracy ±(0.5% of reading +1 V)
Resolution 0.1 V
Time measurement
Basic inaccuracy ±0.1% of reading ±1 digit
Storage of measured values
Torkel stand alone
Time (max) 10 h
Time interval 6 s
Torkel Win
Time (max) 24 h
Time interval 1 – 24 s
Load section
Battery voltage 10 – 60 V DC
Max. current 270 A
Max. power 15 kW
Load patterns Constant current, constant power, con-
stant resistance, current or power profile
Current setting
0-270.0 A (2999.9 A)
1)
Power setting 0-15.00 kW (299.99 kW)
1)
Resistance setting 0.1-2999.8 Ω
Battery voltage
range
2 ranges, selected automatically at start
of test
Stabilization (For
internal current
measurement)
±(0.5% of reading + 0.5 A)
Battery
voltage
Highest permissi-
ble current
Resistor ele-
ment (Nominal
values)
Range 1 10 – 27.6 V 270 A 0.069 Ω
Range 2 10 – 55.2 V 270 A
0.138 Ω
1) Maximum value for a system with more than one load unit
Inputs, maximal values
EXTERNAL CURRENT
MEASUREMENT
1 V DC, 300 V DC to ground. Current
shunt should be connected to the nega-
tive side of the battery
START / STOP Closing / opening contact
Closing and then opening the contact
will start / stop Torkel. It is not possible
to keep the contacts in closed position.
(Min. time open is 25 ms).
Delay until
start
200 – 300 ms
Stop delay 100 – 200 ms
Battery 60 V DC, 500 V DC to ground
VOLTAGE SENSE 60 V DC, 500 V DC to ground
SERIAL < 15 V
ALARM 250 V DC 0.28 A
28 V DC 8 A
250 V AC 8 A
Outputs, maximal values
Torkel 820
Specifications are valid at nominal input voltage and an ambient
temperature of +25°C, (77°F). Specifications are subject to change
without notice.
Environment
Application field The instrument is intended for use in
high-voltage substations and industrial
environments.
Temperature
Operating
0°C to +40°C (32°F to +104°F)
Storage &
transport
-40°C to +70°C (-40°F to +158°F)
Humidity 5% – 95% RH, non-condensing
CE-marking
LVD Low Voltage Directive 73/23/ EEC am.
by 93/68/EEC
EMC EMC Directive 89/336/EEC am. by
91/263/EEC, 92/31/EEC and 93/68/EEC
Standards
Safety standards IEC 61010-1:2001 Incl. national dev. for
US and CA
EN 61010-1:2001
EMC standards
EN 61326: 1997+A1:1998+A2:2001
General
Mains voltage 100 – 240 V AC, 50 / 60 Hz
Power consump-
tion (max)
150 W
Protection Thermal cut-outs, automatic overload
protection
Dimensions
Instrument
210 x 353 x 700 mm
(8.3” x 13.9” x 27.6”)
Transport case 265 x 460 x 750 mm
(10.4” x 18.1” x 29.5”)
Weight
22.3 kg (49.2 lbs)
40.4 kg (89.1 lbs) with accessories and
transport case
Display LCD
Available lan-
guages
English, French, German, Spanish,
Swedish
Measurement section
Current measurement
Display range 0.0 – 2999 A
Basic inaccuracy ±(0.5% of reading +0.2 A)
Resolution 0.1 A
Internal current measurement
Range 0 – 300 A
Input for clamp-on ammeter
Range 0 – 1 V
mV/A-ratio
Software settable, 0.3 to 19.9 mV/A
Input impedance >1 MΩ
Voltage measurement
