CHAPTER 6 FREEZING SYSTEM DIAGRAM
CHAPTER 7 HYGIENE
The ice cream mix and other food materials are an ideal ground for mildew and
bacteria to proliferate to eliminate them, it is necessary to thoroughly wash and
clean all parts in contact with the food. Stainless steel and plastic materials, as well
as rubber used in the construction, and also their particular shapes are designed
for easy cleaning, but cannot prevent proliferation of mildew and bacteria if not
properly cleaned.
NOTE
New machine should be cleaned and sterilized totally before first time using.
NOTE
It is advised to wash all the parts which touch the food after every working day.
CHAPTER 8 SAFETY DEVICE
8.1 Safety Device Position
Separator of oil
and liquid
Cylinder door open
magnetic sensor
Compressor thermal overload
relays (inside of the electrical box)
Motor thermal overload relays (inside
of the electrical box)
