Technical Support 1-800-345-8172 CASHFLOW SC66 Page-9
www.meiglobal.com Part # 252053040 Y1
INSTALLATION
Eight pin harness connector
Installing The Bill Entry Guide
• To install the bill entry guide, just slide onto the Acceptor Module until it locks into place.
No screws are required. If the bill entry guide has lights, you will have to first connect the har-
ness from the bill entry guide to the eight pin connector located on the left hand side of the face
of the Acceptor Module.
Acceptor Module
Bill Entry Guide
To Next Page
