5.3.5 Antenna Requirements
Table 31 Requirements for antenna index
Network
Band
VSWR
Gain
Effi.
SAR
TRP
TIS
Mode
Peak
Avg.
(dBm)
(dBm)
Table 32 Requirements for diversity antenna index
Mode
Band
VSWR
Gain /Avg.
Efficiency
ρ
Isolation
GSM
900
<2.5:1
>-7dBi
>20%
<0.5
<-8dB
GSM
900
<2.5:1
>0dBi
>-4dBi
>40%
<1.6W/Kg
29
<-102
1800(DCS)
26
<-102
WCDMA
Band1
19
<-102
Band8
19
<-102
TDD-LTE
Band34
19
<-94
Band38
19
<-94
Band39
19
<-94
Band40
19
<-94
Band41
19
<-94
FDD-LTE
Band1
19
<-94
Band3
19
<-94
Band5
19
<-94
Band7
19
<-94
Band8
19
<-94
Band20
19
<-94
Band28
19
<-94
