LTE-FDD @ PF = 64（USB disconnect）
3.04
mA
LTE-FDD @ PF = 32（USB disconnect）
3.82
mA
GSM basic power
consumption
EGSM900 PCL=5(4UP) @ 31.7 dBm
284.7
mA
DCS1800 PCL=0 @ 29.6 dBm
243.2
mA
WCDMA basic
power
consumption
WCDMA B1 @ 22.98dBm
568.8
mA
WCDMA B1 @ 10.3 dBm
307.3
mA
WCDMA B1 @ 0.1 dBm
268.6
mA
WCDMA B1 @ -53.5 dBm
250.8
mA
WCDMA B8 @ 22.98dBm
621.9
mA
WCDMA B8 @ 10.3 dBm
315.5
mA
WCDMA B8 @ 0.1 dBm
251.5
mA
WCDMA B8 @ -53.5 dBm
245.6
mA
LTE basic power
consumption
LTE B1@21.9dBm
626.7
mA
LTE B1@10.9dBm
386.5
mA
LTE B1@0.4dBm
316.9
mA
LTE B1@-46.5dBm
304.5
mA
LTE B8@22.7dBm
642.8
mA
LTE B8@9.9dBm
361.5
mA
LTE B8@0.5dBm
307.6
mA
LTE B8@-45.5dBm
295.6
mA
LTE B41@21.1dBm
447.2
mA
LTE B41@10.5dBm
322.8
mA
LTE B41@1.25dBm
253.6
mA
LTE B41@-48.3dBm
245.1
mA
