Rear Panel & Functions
5. Digital Inputs (All inputs support up to 24bit, 192 kHz and DSD):
• AES/EBU: AES/EBU (XLR) digital audio input
• COAX: SPDIF (RCA) digital audio input
• TOS: SPDIF (TOSLINK) digital audio input
• USB Audio: USB Audio digital input (DSD128, DXD and full MQA
®
unfolding)
• USB Media: USB thumbdrive/stick direct file playback, supports up to 24bit,
192kHz and accepts AAC, AIFF, ALAC, FLAC, MP3, WAV, WMA, MQA
®
and
DSD in DSF or DFF file formats
6. Analog Line Output:
• Left and Right Balanced (XLR) Connectors
• Left and Right Un-Balanced (RCA) Connectors
• Output Levels:
XLR outputs: 7.0V (+19.1dBu)
RCA outputs: 3.5V (+13.1dBu)
7. Network/Ethernet interface(RJ45) for streaming and network media playback using
mConnect Control app. Stream and playback files up to 24bit, 192kHz and DSD plus
full MQA
®
unfolding. The MA3 is UPnP/DLNA compatible and is Roon Ready/Roon
Endpoint.
Auxiliary USB type A connector located below the Ethernet port is an optional WiFi
port (WiFi adaptor not included)
8. System
Remote:
• Wired RS232 communication port
Service:
• RESET: Factory Reset button (for support purposes only)
012
Rear Panel & Functions MA3 Integrated D/A Converter Manual
meitner © 2020 Meitner Audio, All Rights Reserved. Meitner Audio reserves the right to amend specifications & design without notice.
