Features & Specifications
2-Channel Digital to Analog Conversions (All Digital Inputs):
• 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz and DSD
• Word lengths up to 24bit
2-Channel 2xDSD/DSD128 and DXD (352 and 384kHz) Digital to Analog Conversion is
supported using the USB Audio input.
2- Channel full MQA
®
unfolding supported via USB Audio and Network inputs.
Available Digital Inputs:
• 1x USB Audio
• 1x AES/EBU (XLR)
• 1x COAX (SPDIF RCA)
• 1x TOS (TOSLINK Optical)
• 1x Network (RJ45)
• 2x USB Media (Type A, USB storage and/or WiFi ports)
• 1x Network/Ethernet interface(RJ45)
Output Impedance: 300Ω balanced (XLR), 150Ω unbalanced (RCA)
Output Levels:
Balanced XLR outputs: 7.0V (+19.1dBu)
Unbalanced RCA outputs: 3.5V (+13.1dBu)
System: System control via serial RS-232
Note:
1. XLR analog outputs are balanced with pin 2 hot, pin 3 cold and pin 1 ground.
2. For proper digital audio data transfer (176, 192kHz and DSD) appropriate high
quality AES/EBU, COAX, TOSLINK and USB 2.0 cables recommended.
007
Features & Specifications MA3 Integrated D/A Converter Manual
meitner © 2020 Meitner Audio, All Rights Reserved. Meitner Audio reserves the right to amend specifications & design without notice.
