Connecting & Operating the MA3
The MA3 has a host of digital inputs :
USB Audio (USB) : USB Audio connection supports up to 24bit, 192kHz PCM, DXD 352
and 384kHz, DSD64 and DSD128 (2xDSD) and MQA
®
using USB 2.0
cables
AES : Balanced digital interface supports up to 24bit, 192kHz and DSD via
XLR 110Ω digital cables.
COAX : COAX S/PDIF interface which supports up to 24bit, 192kHz and DSD
via RCA 75Ω digital cables.
TOS : TOSLINK optical interface supports up to 24bit 192kHz and DSD via
TOSLINK optical interface.
NET : Ethernet (RJ45) network interface. Networking connection for both
streaming media, network file playback using mConnect Control app.
Stream files up to 24bit, 192kHz and DSD plus full MQA
®
unfolding.
It is UPnP/DLNA compatible and is Roon Ready/Roon Endpoint.
USB Media : For connection to USB flash drives (FAT32 or NTFS formatted).
Connect USB flash drives to playback audio files using the mConnect
Control app. For Android and IOS tablets use the mConnect Control
HD app to use the landscape interface option. File playback supports
up to 24bit,192kHz and accepts AAC, AIFF, ALAC, FLAC, MP3, WAV,
WMA, MQA
®
file formats. It also accepts DSD64 playback (via DoP
streaming) in DSF or DFF file formats. The MA3 provides full MQA
®
unfolding when playing back MQA
®
files (up to 192kHz).
014
Connecting & Operating the MA3 MA3 Integrated D/A Converter Manual
