User Manual for Mellanox ConnectX®-3 10/40 Gigabit Ethernet Adapters for Dell PowerEdge Servers Rev 1.1
Mellanox Technologies
9
List of Figures
Figure 1: Mellanox ConnectX-3 Dual Port 40GbE QSFP+ Network Adapter Full Height Bracket 16
Figure 2: Mellanox ConnectX-3 Dual Port 10GbE SFP+ Network Adapter Ful
l Height Bracket .17
Figure 3: Life Cycle Controller Main Configuration System Setup Menu
. . . . . . . . . . . . . . . . . . .94
Figure 4: Main Configuration Page Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Figure 5: Main ConfiguratioP page - iSCSI Configuration -
iSCSI General Parameters . . . . . . .101
Figure 6: Main Configuration Page - iSCSI Configuration -
iSCSI Initiator Parameters . . . . . . .102
Figure 7: Main Configuration Page - iSCSI Configuration - iSCSI Target Parameters . . . . . . . .103
