SpecificationsRev 1.1
Mellanox Technologies
90
Table 18 - Mellanox ConnectX-3 Dual 10GbE KR Blade Mezzanine Card Specifications
Physical
Size: 3.4in. x 3.3in. (88 mm x 84mm)
Protocol Support
Ethernet: 10GBASE-KR, 10GBASE-KX4, 1000BASE-KX
Data Rate:
1/10Gb/s – Ethernet
PCI Express Gen3: SERDES @ 8.0GT/s, 8 lanes (2.0 and 1.1 compatible)
Power and
Environmental
Voltage: 12V, 3.3Vaux
Typ Power: 4.84
Max Power: 5.87
Temperature: Operational 0°C to 65°C
Non-operational 0°C to 70°C
Humidity: 90% relative humidity
a
a. For both operational and non-operational states
Air Flow: 200LFM
b
b. Air flow is measured ~1” from the heat sink between the heat sink and the cooling air inlet.
Regulatory
Safety: IEC/EN 60950-1:2006
ETSI EN 300 019-2-2
IEC 60068-2- 64, 29, 32
RoHS: RoHS-R6
