7 Specifications
7.1 MCX4421A-XCQNSpecifications
Physical Size: 2.67 in. x 4.33 in. (68.00 mm x 110.05 mm)
Connector: Dual SFP28 (copper and optical)
Protocol Support Ethernet: 10GBASE-SR, 10GBASE-LR, 10GBASE-ER, 10GBASE-CX4, SGMII,
1000BASE-X
Data Rate: 1/10 Gb/s Ethernet
PCI Express Gen3: SERDES @ 8.0GT/s, 8 lanes (2.0 and 1.1 compatible)
Power and Environmental Voltage: 12V, 3.3V
Power Cable Type
Typical Power
(a)
Passive Cables 9W
Maximum Power Passive Cables 10.63W
1.5W Active Cables 13.63W
Maximum power available through SFP28 port: 1.5W
Temperature Operational 0°C to 35°C
Non-operational -40°C to 70°C
Humidity
90% relative humidity
(b)
Airflow
(c)
(port-to-heatsink)
Passive/Active Cables 200LFM
Regulatory Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
Notes: a. Typical power for ATIS traffic load.
b. For both operational and non-operational states.
c. Simulated inside an air tunnel (15.2 mm high and 73 mm wide). Airflow direction - port to heatsink.
7.2 MCX4411A-AC[A/U]NSpecifications
Physical Size: 2.67 in. x 4.33 in. (68.00 mm x 110.05 mm)
