Humidity
90% relative humidity
(b)
Airflow
(c)
(port-to-heatsink)
Passive/Active Cables 300LFM
Regulatory Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
Notes: a. Typical power for ATIS traffic load.
b. For both operational and non-operational states.
c. Simulated inside an air tunnel (15.2 mm high and 73 mm wide). Airflow direction - port to heatsink.
7.8 Board Mechanical Drawing and Dimensions
7.8.1 Mechanical Drawing of Single-port 10/25 Gb/s Adapter Cards
For the 3D Model of the card, please refer to 3D Models at http://www.mellanox.com/page/3d_models.
All dimensions are in millimeters. All the mechanical tolerances are +/- 0.1mm.
