1. PLAY (®) Button
2. OPEN/CLOSE Button
3. Disc Compartment
4. STANDBY/STOP Button
To return to the Standby mode while the unit
is on, press and hold the STANDBY/STOP
button for two seconds then release; the unit
will be turned off and the Standby indicator
will light on.
5. STANDBY/POWER ON Indicator
6. Display
7. Remote Sensor
6
LOCATION OF CONTROLS
FRONT
1. AC Power Cord
2. Stereo Audio Left/Right Output Jacks
3. Video Output Jack
4. S-Video Output Jack
5. Coaxial Digital Audio Output Jack
6. Component Video (Y, P
B, PR) Output Jacks
7. PROGRESSIVE SCAN ON/OFF Switch
REAR
