6
LOCATION OF CONTROLS
POWER SOURCE
Insert the AC plug (with the 2 blades) into a conveniently located AC outlet having 120V,
60Hz.
NOTE: The AC plug supplied with the unit is polarized to help minimize the possibility of
electric shock. If the AC plug does not fit into a nonpolarized AC outlet, do not file or cut
the wide blade. It is the user’s responsibility to have an electrician replace the obsolete
outlet.
1. Video Cassette Tape Indicator–When a video cassette tape is inserted, the indicator will
light.
2. VCR Mode Indicator
3. Status/Time Display
4. DVD Mode Indicator
5. Disc Indicator–When a disc is inserted into the disc tray, after loading the disc, the indicator
will light.
6. Timer Indicator
7. REC Indicator
DISPLAY
