MEMUP MEDIADISK - Installation Connection (Audio and Digital Outputs); Connection with 2 CH of Normal TV; Connection with Coaxial output; Connection with Optical output

- 5 -
4、Connection with 2 CH of Normal TV
5、Connection with Coaxial output
6、Connection with Optical output
Connect left (white) and right
(red) sound output to the
appropriate terminal of your TV or
Hi-Fi
When you have a multi channel
decoder/ amplifier with coaxial
input, you can enjoy 5.1CH high
quality sound through coaxial
cable. Illustration on the top
shows how to connect with
coaxial cable
When you have a multi channel
decoder/amplifier with optical
input, you can enjoy 5.1 high
quality sounds through optical
cable. Illustration on the top
shows how to connect with optical
cable.
