Machine installation
Check list
Before starting installation, check that all the accessories, whether standard or
optional, supplied with the machine are present. The basic version of the SHARK
282 2---SPEED machine is supplied complete with:
CHARACTERISTICS
STANDARD OPTIONAL
Base with large swarf collection drawer, removable coolant tank and
electropump for band saw lubrication/cooling
n
Double return spring for head upstroke n
Hydraulic transducer for blade tension display n
2.950x27x0.9 bimet al blade for solid and section materi als n
Right/left slide locking unit, with quick locking/release n
Vice with rapid jaw positioning n
Blade cleaning brush n
Designed for transpallet handling systems n
Electric control panel (totally identifiable cabling, stand---by, main switch with
lockable panel---closing device, speed switch, emergency device,
thermal---magnetic overload cutout, minimum voltage relay, voltage drop
protection, 24 V low--- voltage plant)
n
Blade protection behind and below blade guide heads n
IP 55 handgrip n
Precision stops for cuts at 0° ,45° ,60° left and 45° right
n
Accessory kit n
Vice control pedal (only with MA version)* n
4/8 pole motor for 36/18 mt./min. spe ed* n
Automatic Vice kit (MA) n
2.950x27x0.9 M2/M42 bimetal band saw n
Cut Control System (CCS) n
Electronic speed control (inverter) 20 to 90 mt/min n
Ø 20 mm measuring rod for cuts to measure with ratchet wrench and lever n
Bar support n
K60/K100 roller table on supply side --- kit 1500 mm n
Feed side roller table support n
Discharge side roller table adaptor n
K60/K100 roller table for discharge side, 1500÷6000 mm n
5 l can of emulsible oil n
*ACCESSORIES AVAILABLE ON REQUEST
The bag of accessories is enclosed in the machine before being packed and
contains:
H 4 and 10 mm Allen keys;
H pipe wrench 10 mm;
H measuring rod for cuts--to--measure;
