Accessory Installation
This chapter provides a list of the available accessories that can be fitted to this
machine, along with assembly instructions.
Automatic vice kit
This pneumatic device can be activated by using the selector on the front of the
machinebase.Themachineissetupforthepassageofpneumaticpipes,for
positioning the pneumatic selector, and for the maximum pressure valve on the
air inlet, on the back of the base. To assemble the Automatic Vice, proceed as
follows:
H drill two 5 mm holes as shown i n the diagram, for fixing the support bracket for
the air treatment unit;
H put the pneumatic valve in the base and fix it using the relevant ring nut;
11
