6--1
Diagrams, exploded
views and replace--
ment parts
This chapter contains functional diagrams and exploded views of the SHARK 282,
including the MA version. This document is intended to help in identifying the
location of the various components making up the machine, giving information
useful in carrying out repair and maintenance operations ; This chapter will also
enable the user to order replacement parts with no risk of misunderstanding, as
all parts are given codes.
Pneumatic diagram (MA version)
VIA
GT A
CMT
CMT
GT A
VIA
VM
VP
Pneumatic components key
VIA Air inlet valve VP Pedal valve CMT Cutter vice
cylinder
GT A Air treatment
unit
VM Manual valve CPT Head holder
cylinder
6
