Description of machine operation
" Select the cut using the polarity change switch according to the type of the
material to be cut (shape, thickness, hardness, etc.).
" Grip the head control lever and start the blade rotating by pressing the
microswitch on the handgrip; the downstroke speed of the head is manually
controlled by the operator.
" The motor starts up and sets the blade in rotary motion; the lubricant/coolant
pump starts up at the same time.
" At the end of the cutting operation, the head can be raised.
