3. Do not install wedges or plates between the transom clamp brackets and
the transom (or jack plate). Refer to Figure 4.
Figure 4
a - Boat transom or jack plate
b - Transom clamp bracket
c - Wedge/plate
Important Information
Rigging boats, which includes proper engine installation, has become more
complex over the years. As a result, we recommend our engines be installed
only by Mercury authorized dealers. If you intend to disregard this
recommendation and install the engine yourself, please make sure to read and
comply with these instructions. Failure to comply with these installation
instructions could lead to serious injury or death.
Boat Horsepower Capacity
!
WARNING
Exceeding the boat's maximum horsepower rating can cause serious injury
or death. Overpowering the boat can affect boat control and flotation
characteristics or break the transom. Do not install an engine that exceeds
the boat's maximum power rating.
OUTBOARD INSTALLATION
118 eng
