2. Thread the lifting eye into the flywheel hub for a minimum of five turns.
Lifting Eye 91‑90455‑‑1
Threads into the flywheel to remove the
powerhead assembly from the
driveshaft housing, or to lift entire
engine for removal/installation.
3. Connect a hoist to the lifting eye.
4. Lift the outboard and place it on the boat transom.
Steering Cable ‑ Starboard Side Routed Cable
1. Lubricate the O‑ring seal and the entire cable end.
3724
95
Tube Ref
No.
Description Where Used Part No.
95
2-4-C with PTFE O-ring seal and entire cable end 92-802859A 1
OUTBOARD INSTALLATION
122 eng
