Available Outboard Mounting Bolts
Part Number Description
67755‑2 ½‑20 x 6.50 in. long (2.75 in. thread)
8M0028080 ½‑20 x 7.50 in. long (2.75 in. thread)
8M0032860 ½‑20 x 8.00 in. long (2.75 in. thread)
CHECKING BOAT TRANSOM CONSTRUCTION
IMPORTANT: Determine the strength of the boat transom. The outboard
mounting locknuts and bolts should be able to hold 75 Nm (55 lb‑ft) of torque
without the boat transom yielding or cracking. If the boat transom yields or
cracks under this torque, the construction of the transom may not be adequate.
The boat transom must be strengthened or the load carrying area increased.
a - Transom yielding under bolt torque
b - Transom cracking under bolt torque
OUTBOARD INSTALLATION
eng 129
