Universal Puller Plate 91‑37241
Removes bearings from gears and the driveshaft.
Pinion Bearing Installation Tool Assembly 8M0038865
Guides the removal and installation of the pinion bearing
Bearing Mandrel Kit 91‑ 83166M
Aids in the removal and installation of bearings and bearing races.
Spring 8M0011503
Applies upward force to the driveshaft for checking forward gear backlash.
Clamp 8M0033741
Used as part of an assembly to provide upward force on the driveshaft to check
forward gear backlash. Part of Pinion Bearing Installation Tool Assembly
91‑899015A02
Backlash Preload Tool 91‑895195T04
Prevents forward gear movement when checking the forward gear backlash.
Gear Housing (2.15:1)
90-8M0125265 eng NOVEMBER 2017 © 2018 Mercury Marine Page 6A-3
