Mercury 175 Verado - Page 114

MAINTENANCE
106
2. Remove the bolts securing the flywheel cover to the rear
mounting posts.
a
b
c
15247
a - Flywheel cover bolts
b - FSM vent hose
c - Engine ventilation hose
3. Lift the flywheel cover off the front mounting post and the
intake resonator.
4. Remove three screws holding the upper flywheel cover to the
lower flywheel cover.
14309
5. Separate the two flywheel cover sub-assemblies to access the
air filter.
