FEATURES AND CONTROLS
58 eng
6. Select button ‑ Selects the System View on‑screen options
and confirm data entries. Holding the select button for two
seconds will pause the slide show if selected in Favorites.
Holding the select button for three seconds will activate the
reset data function (except when in the slide show function).
Holding the select button for five seconds or more will bring
up the Home page.
7. Neutral LED ‑ The neutral LED illuminates when engine is in
neutral gear position. It also flashes when throttle only is
activated.
NOTE: Gear position is determined by sensing the position of
the shift actuator on the engine, not the position of the control
handle.
8. Active LED ‑ The active LED illuminates to show the remote
control is active and ready for use.
9. Throttle only/station select button ‑ Allows the boat operator
to increase engine RPM for warm‑up, without shifting the
engine into gear. To engage throttle only, move the control
handle into the neutral position. Press the throttle only
button while moving the control handle ahead to the forward
detent. The horn will sound once and the neutral light will
start flashing. The horn will sound twice when throttle only is
engaged. Advance throttle to increase engine RPM. To
disengage, return control handle to neutral position and
press the throttle only button. Engine RPM is limited to
prevent engine damage. Pressing the station select button
at an inactive helm initiates a helm transfer. Refer to Helm
Transfer.
a - Neutral LED
b - Select button
c - Arrow trackpad
d - Throttle only/
station select
button
e - Active LED
d
b
a
c
e
5187
