FEATURES AND CONTROLS
eng 67
8. Neutral LEDs ‑ The neutral LEDs illuminate when engines
are in neutral gear position. The lights will flash when in
throttle only mode.
NOTE: Gear position is determined by sensing the position of
the shift actuator on the engine, not the position of the control
handle.
9. Active LED ‑ The active LED illuminates to show the remote
control is active and ready for use.
10.Sync LED ‑ The sync LED illuminates when the RPM of the
two engines are being synchronized by the DTS system.
a - Neutral LEDS
b - Select button
c - Arrow trackpad
d - Sync LED
e - Throttle only/station
select button
f - Active LED
SYNCHRONIZING ENGINES
The auto synchronizing feature, when engaged, will
automatically adjust all engine speeds to match the speed of the
starboard engine.
5270
ACTIVE
SYNC
THROTTLE
ONLY
STATION SELECT
a
b
c
d
e
f
