Mercury 225 OptiMax DTS User Manual

200/225 OPTIMAX DTS
Page 22 / 42 90-10234050
Copper Battery Cable Wire Gauge Size
Wire Gauge Size Number SAE
Models 6-25 hp 30-115 hp (except OptiMax) 125-250 hp (except OptiMax) OptiMax/Verado
Cable Length
2.4 m (8 ft.) 8
1.
6
1.
- -
2.7 m (9 ft.) 6 4 - -
3.0 m (10 ft.) 6 4
6
1.
-
3.4 m (11 ft.) 6 4 4 -
3.7 m (12 ft.) 6 4 4
4
1.
4.0 m (13 ft.) 6 2 4 2
4.3 m (14 ft.) 4 2 4 2
4.6 m (15 ft.) 4 2 4 2
4.9 m (16 ft.) 4 2 2 2
5.2 m (17 ft.) 4 2 2 2
5.5 m (18 ft.) 4 2 2 2
5.8 m (19 ft.) 4 2 2 2
6.1 m (20 ft) 4 2 2 2
6.4 m (21 ft.) 2 1 2 1
6.7 m (22 ft.) 2 1 2 1
7.0 m (23 ft.) 2 1 2 1
7.3 m (24 ft.) 2 1 2 1
7.6 m (25 ft.) 2 1 2 1
7.9 m (26 ft.) 2 1/0 1 1/0
8.2 m (27 ft.) 2 1/0 1 1/0
8.5 m (28 ft.) 2 1/0 1 1/0
8.8 m (29 ft.) 2 1/0 1 1/0
9.1 m (30 ft.) 2 1/0 1 1/0
9.4 m (31 ft.) 2 1/0 1 1/0
9.8 m (32 ft.) 2 1/0 1 1/0
10.1 m (33 ft.) 2 2/0 1/0 2/0
10.4 m (34 ft.) 2 2/0 1/0 2/0
10.7 m (35 ft.) 1 2/0 1/0 2/0
11.0 m (36 ft.) 1 2/0 1/0 2/0
11.3 m (37 ft.) 1 2/0 1/0 2/0
11.6 m (38 ft.) 1 2/0 1/0 2/0
11.9 m (39 ft.) 1 2/0 1/0 2/0
12.2 m (40 ft.) 1 2/0 1/0 2/0
1.
Standard (original) cable length and wire gauge size.

Mercury 225 OptiMax DTS Specifications

General

Brand	Mercury
Model	225 OptiMax DTS
Category	Outboard Motor
Language	English
