Mercury 25 4-Stroke User Manual

MAINTENANCE
50
IMPORTANT: The engine must be run during flushing in order to open the thermostat and circulate water through
the water passages.
!
WARNING
To avoid possible injury when flushing, remove the propeller. Refer to Propeller Replacement, following.
1. Place the outboard in either the operating position (vertical) or in a tilted position.
2. Remove propeller. Refer to Propeller Replacement.
3. Thread a water hose into the rear fitting. Partially open the water tap (1/2 maximum). Do not open the water
tap all the way, as this allows a high pressure flow of water.
IMPORTANT: Do not run engine above idle when flushing.
4. Shift outboard into neutral. Start the engine and flush the cooling system for at least 5 minutes. Keep engine
speed at idle.
5. Stop the engine. Turn off the water and remove hose. Reinstall the propeller.
ob00367
Top Cowl Removal And Installation
REMOVAL
1. Unlock the rear latch by pushing lever down.
ob00368
2. Lift rear of cowl and disengage front hook.
ob00369
INSTALLATION
1. Engage the front hook and push cowl back over the cowl seal.
2. Push cowl down and move the rear latch lever up to lock.

Mercury 25 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	25 hp
Cylinders	2
Fuel Induction System	Electronic Fuel Injection (EFI)
Full Throttle RPM Range	5000-6000 RPM
Starting System	Electric
Steering	Remote or Tiller
Shaft Length	15 in / 20 in
Dry Weight	157 lbs
Fuel Tank Capacity	External
Oil Capacity	1.5 L (with filter)
