3. Determining remote control cable length: A guideline for determining the
proper length for a remote control cable is dimensions A plus B plus 300
mm (1 foot).
a - Center of transom
NOTE: The minimum bend radius for a remote control cable is typically 203
mm (8 in.). Avoid making sharp bends.
4. Connecting remote control cables to the remote control box: Remove the
back panel by loosening two screws.
a - Back panel
