Mercury 300XS OptiMax - Storage Preparation

MAINTENANCE
79
1. Lubricate the propeller shaft splines with Anti-Corrosion
Grease.
2. Install the propeller hub assembly, propeller, washer,
Belleville washer, washer, and propeller nut onto the propeller
shaft.
94
a
b
c f
d
e
2693
a - Propeller hub
assembly
b - Propeller
c - Washer
d - Belleville washer
e - Washer
f - Propeller nut
Tube Ref No. Description Where Used Part No.
94
Anti-Corrosion
Grease
Propeller shaft
splines
92-802867A1
3. Place a block of wood between the gearcase and propeller
and torque the propeller nut.
or119
