Mercury 50 - Specifications; Product Diagram

Models Without Power Trim*
30.
I - Top Cowl
2 - Rear Cowl Latch
3 - Water Pump " Tell - Tale " Outlet
4 - Exhaust Relief Outlet
5 - Drive Shaft Housing
6 - Dyna Float Suspension
7 - Water Discharge
S - Trim Tab
9 - Tr~m Tab Adjustment Bolt
10 - Jet Prop Exhaust
11 - Quicks~lver Propeller
12
- Skeg
13
- Oil Reservoir Tank Cap
14 - Oil Level Sight Gauge
15
- Fuel Line Connector
16
- Engine Wiring HarnessIBattery Cables
17
- Steering Arm/Bracket
18 - Tilt Tube
19
- Auxiliary Tilt Switch
20
- Swivel Bracket
21
- Transom Bracket
22
- Trim Adjustment Pin
23
- Manual Tilt Release Valve
24
- Lubricant VENT Plug (2)
25
- Anti - Ventilation Plate
26
- Water Intake
27
- Speedometer Pickup Up
28
- Gear Housing
29
- Lubricant Fill Plug
30
- Tilt Release Lever
SPECIFICATIONS
I Recommended Spark Plug1 I NGK BU8H
I
I
Recommended Oil
Recommended
Gasol~ne
Uuicksilver
2 - Cycie Outboard Oil
Any leaded or unleaded (lead
- free) gasoline,
with a minimum posted octane rating of 87
(research
oztane number 90)
'International Only
Battery Rating
Transom Height
Minimum Reserve Capacity Rating of
100 Minutes and Cold Cranking
Amperage of 350 Amperes
Long Shaft
- 20 in. (508mm)
'Use NGK-BUZ8H where radio frequency interference (RFI) suppression is requtred.
