Mercury 50 User Manual

FEATURES & CONTROLS
31
ob00615
a
b
c
a - Release position
b - Lock position
c - Tilt support pin
Lowering To Run Position
1. Raise outboard slightly and pull out the tilt support pin. Lower the outboard.
2. Move the tilt lock lever down to the lock position.
SHALLOW WATER OPERATION
The shallow water drive feature on the outboard allows you to position the outboard at a higher tilt angle to prevent
hitting bottom.
IMPORTANT: While in shallow water, operate the outboard at slow speed and keep the cooling water intake
submerged.
Engaging Shallow Water Drive
1. Reduce engine speed to idle.
2. Push the tilt lock lever up to the release position.
3. Rotate knob to engage the shallow water drive bracket.

Mercury 50 Specifications

General

Horsepower	50 hp
Cylinders	3
Steering	Remote
Starting	Electric
Displacement	995 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	18 amp
Shaft Length	20" / 508 mm
Dry Weight	112 kg
Engine Type	4-Stroke
