MAINTENANCE
59
3933
b
c
d
a
a - Cover
b - Filter
c - O-ring seal
d - Sight bowl
2. Wash sight bow and filter in cleaning solvent.
3806
Carburetor Fuel Bowl
!
WARNING
Avoid serious injury or death from gasoline fire or explosion. Carefully follow all fuel system service instructions.
Always stop the engine and do not smoke or allow open flames or sparks in the area while servicing any part
of the fuel system.
1. Loosen main jet plug on side of carburetor 1 turn to drain fuel.
3938
2. Dispose of fuel properly.
