MAINTENANCE
67
2. Lubricate the following with Quicksilver or Mercury Precision Lubricants 2-4-C with Teflon or Special Lubricant
101.
Swivel Bracket - Lubricate through fitting.
ob00635
Tilt Tube - Lubricate through fitting.
Co-Pilot Shaft (Tiller Handle Models) - Lubricate through fitting. Move the steering friction lever back
and forth while lubricating.
3089
a
b
a
a - Tilt Tube b - Co-pilot shaft
Lubricate threads of transom clamp screws (if equipped).
ob00637
Shift Handle (Tiller Handle Models) - Lubricate through fittings.
3091
Steering Cable Grease Fitting (If equipped) - Rotate steering wheel to fully retract the steering cable
end into the outboard tilt tube. Lubricate through fitting.
