Mercury 50 User Manual

FEATURES & CONTROLS
44
BASIC TILTING OPERATION
Move tilt lock lever to the tilt position. Tilt outboard to desired
position and lock in place by moving the tilt lock lever back to the
lock/run position.
a
b
26802
a - Tilt position b - Lock/run position
SHALLOW WATER OPERATION
When operating the boat in shallow water, the outboard can be
adjusted and locked at a higher tilt angle. Operate the outboard at
slow speed while tilted up for shallow water operation. Keep the
cooling water intake holes submerged in the water and continue to
check for water discharge from the water pump indicator hole.
TILTING OPERATION
Tilting To Full Up Position
1. Stop the engine. Move the tilt lock lever to the tilt position. Take
hold of the top cowl grip and raise outboard to full tilt up
position. Lock the outboard in place by moving the tilt lock
lever to the lock/run position.
27385

Mercury 50 Specifications

General

Horsepower	50 hp
Cylinders	3
Steering	Remote
Starting	Electric
Displacement	995 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	18 amp
Shaft Length	20" / 508 mm
Dry Weight	112 kg
Engine Type	4-Stroke
