Mercury 50 User Manual

OPERATION
68
3. If starter rope is intact, pull rope out of the rewind housing and
tie a knot in the rope. Remove retainer from end of rope and
untie the retainer knot.
3084
a
b
4. Remove the rewind starter.
3085
!
WARNING
High voltage is present any time the key is turned on, especially
when starting or operating the engine. Do not touch ignition
components or metal test probes and stay clear of spark plug
leads when performing live tests.
!
WARNING
The exposed moving flywheel can cause serious injury. Keep
your hands, hair, clothing, tools, and other objects away from
engine when starting or running the engine. Do not attempt to
reinstall the rewind starter assembly or top cowl when engine
is running.

Mercury 50 Specifications

General

Horsepower	50 hp
Cylinders	3
Steering	Remote
Starting	Electric
Displacement	995 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	18 amp
Shaft Length	20" / 508 mm
Dry Weight	112 kg
Engine Type	4-Stroke
