CYLINDER BLOCK
AND CRANKCASE
90-857138R1 MA
Y 2000
Page 4B–21
16.
Remove the breather cap.
a
b
c
a-
Screw (2)
b-
Breather Cap
c-
Gasket
17.
Remove the breather tubes and wave washers.
a
b
a-
Breather T
ube (2)
b-
W
ave W
asher (2)
152
