CYLINDER BLOCK AND CRANKCASE
Page 4B–20 90-857138R1 MAY 2000
14. Pry out the upper oil seal.
a
a-Upper Oil Seal
15. If the replacement of the upper ball bearing is necessary, use puller 91-83165M and pull
out the bearing.
91-83165M
a
b
a-Upper Ball Bearing
b-Puller 91-83165M
