CHARGING SYSTEM
90-857138R1 MAY 2000 Page 2B-5
Rectifier (Battery Charging)
Installation
1. This rectifier kit provides DC current for battery charging, and must be installed in con-
junction with Alternator Kit.
2. Secure rectifier to crankcase cover, as shown.
57352
57353
a
b
f
e
d
c
a-Threaded Boss
b-Alternator Leads
c-Rectifier
d-Screw and Lockwasher
e-Clamp
f-Fuse Holder
