Mercury 75 OptiMax User Manual

FUEL AND OIL
40 eng
4. Oil filler caps with a dipstick ‑ Check the oil level on the
dipstick. The first set of holes indicates 0.94 liters (1 US qt)
low. The second set of holes indicates 1.89 liters (2 US qt)
low. The third set of holes indicates 2.83 liters (3 US qt) low.
a - Add 0.94 liters (1 US qt)
b - Add 1.89 liters (2 US qt)
c - Add 2.83 liters (3 US qt)
5. Oil filler caps with a chain ‑ Check the oil level on the chain.
The first ball marker indicates 0.94 liters (1 US qt) low. The
second ball marker indicates 1.89 liters (2 US qt) low.
a - Add 0.94 liters (1 US qt)
b - Add 1.89 liters (2 US qt)
6.
Slowly fill the oil tank with the specified oil. Do not overfill.
Add only enough oil to bring the oil level up to the bottom of
the fill neck.
a
b
c
37143
a
b
37146

Mercury 75 OptiMax Specifications

General

Engine Type	2-stroke
Displacement	1526 cc
Horsepower	75 hp
Alternator	60 amp / 756 watt
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-5750 rpm
Steering	Remote
Fuel Induction System	2-stage direct fuel injection
Shaft Length	20"
Weight	170 kg
